M6 105 Mechanical

M6 colorways are custom-built to order and undergo multiple quality inspections before shipment. Current lead time is 20–25 business days — worth the wait.

Crankset Availability Update: All cranksets are currently available in 52-36T chainrings. If you need 50-34T, please contact our support team before placing your order.

Available Size:
XS | S | M | L | XL | XXL
HYPER HANDLEBAR WIDTH
360mm | 380mm | 400mm | 420mm
Crank Length
165mm | 170mm | 172.5mm

More Details

Build Specs

~8.6kg (Size M, without pedals)

Frame: T700 + T800 + M40 + M60 carbon fiber
Fork: Full carbon
Headset: 1-1/2″
Sizes: XS / S / M / L / XL / XXL
rame Weight: Approx. 900 g (Size M, unpainted)

Shifters: SHIMANO 105 ST-R7120
Front Derailleur: SHIMANO 105 FD-R7100-F
Rear Derailleur: SHIMANO 105 RD-R7100
Crankset: SHIMANO 105 FC-R7100, 50/34T
Cassette: SHIMANO 105 CS-R7101, 11–34T
Chain: SUMC
Brakes: Hydraulic Disc

Wheelset: Unaas Hard D50
Tires: CST Wire Bead 700×28C, black sidewall
Axles: Front M12×P1.0×114L / Rear M12×P1.0×163L

Integrated Handlebar: Hyper Integrated Handlebar
Stem Length Options: 85 / 95 / 105 / 115 / 125 mm
Bar Tape: Selle Italia Smart Tape Comfort
Saddle: Velo Saddle
Seatpost: AERO Seatpost

Shell: T47-85.5

What’s in the Box

Your new bike arrives 90% assembled. In addition to the pre-assembled frameset and components, the accessory box includes the following items for final installation:

Saddle
Seatpost
Seatpost Wedge
Steel Rail Saddle Clamp
Computer Mount Kit
Includes 1 UDH derailleur hanger (pre-installed). No spare hanger included.
Seatpost Dust Cover
Water Bottle Cage Bolts (x4)
Assembly Tool Kit
Pedal

Geometry Chart
